Velocity Series Louvers
Welcome to the future of building protection and efficiency. Our Velocity™ series high-performance louvers are engineered to meet the most stringent impact and wind-driven rain tests, ensuring your structure remains safeguarded under the most demanding conditions. From hurricane-force winds to heavy rain, Velocity offer superior protection without compromising on airflow or aesthetics.
COMING SOON! Model VS51T – Velocity Series FEMA louver
The Velocity Series™ louvers are a high performance louvers that are in testing to meet FEMA standards. As with all of our products, they are made in the USA.
Model VS5321 – AMCA 540 & 550 Velocity Series
The Velocity Series™ louvers are a high performance louvers that have passed the rigorous AMCA 540 and 550 testing for missile impact and high velocity wind driven rain. As with all of our products, they are made in the USA.
STANDARD CONSTRUCTION – Front module
- Material: Extruded Aluminum 6063-T6
- Frame: 3” (76mm) deep, .081” (2.1mm) wall thickness
- Blades: 3” (76mm) deep, .063” (1.6mm) wall thickness
- Blade Spacing: 1.25” (31.8mm) on center
- Sill Flashing: 0.63″ (1.6mm) formed aluminum w/end dams
- Finish: Mill
STANDARD CONSTRUCTION – rear module
- Material: Extruded Aluminum 6063-T6
- Frame: 2” (51mm)deep, .081” (2.1mm) wall thickness
- Blades: 2” (51mm)deep, .063” (1.6mm) wall thickness
- Blade Spacing: 0.9375” (23.8mm) on center
- Finish: Mill
Model VS653 | AMCA 540 & 550 Velocity Series
The Velocity Series™ louvers are a high performance louvers that have passed the rigorous AMCA 540 and 550 testing for large impact and high velocity wind driven rain. As with all of our products, they are made in the USA.
STANDARD CONSTRUCTION
Front Fixed Blade Louver
- Material: Extruded Aluminum 6063-T6
- Frame: 6” (152 mm) deep, .081”/ 0.125″ (2.1 / 3.2 mm) wall thickness
- Blades: 6” (152 mm) deep, .081” (2.1 mm) wall thickness
- Blade Spacing: 4.25” (108 mm) on center
- Finish: Mill
Rear Adjustable Blade Louver
- Material: Aluminum 5005-H34, Aluminum 6063-T6
- Frame: 6.875” (175 mm) deep, .080” (2.1 mm) wall thickness
- Blades: adjustable angle, .080” (2.1 mm) wall thickness
- Blade Spacing: 5.25” (133 mm) on center
- Finish: Mill
Model VS537 | AMCA 540 & 550 Velocity Series
The Velocity Series™ louvers are a high performance louvers that have passed the rigorous AMCA 540 and 550 testing for large impact and high velocity wind driven rain. As with all of our products, they are made in the USA.
STANDARD CONSTRUCTION
Front Fixed Blade Louver
- Material: Extruded Aluminum 6063-T6
- Frame: 5” (127 mm) deep, .081” (2.1 mm) wall thickness
- Blades: 5” (127 mm) deep, .063” (1.6 mm) wall thickness
- Blade Spacing: 2.0625” (52.4 mm) on center
- Sill Flashing: 0.063″ (1.6 mm) formed aluminum w/end dams
- Finish: Mill
Rear Adjustable Blade Louver
- Material: Aluminum 5005-H34, Aluminum 6063-T6
- Frame: 6.875” (175 mm) deep, .080” (2.1 mm) wall thickness
- Blades: adjustable angle, .080” (2.1 mm) wall thickness
- Blade Spacing: 5.25” (133 mm) on center
- Finish: Mill
Model SP537V | AMCA 540 & 550 Storm Performance Louvers 5 Inches
Storm Performance Louvers provide optimum performance against the elements. Vertically mounted blades are specifically designed and tested to prevent infiltration of wind driven rain while allowing maximum airflow through the unit. Depth is 5″ (127 mm). Performance data is certified by AMCA, including the 540 and 550 performance tests. As with all of our products, they are made in the USA.
STANDARD CONSTRUCTION
- Material: Extruded Aluminum 6063-T6
- Frame: 5” (127 mm) deep, .081” (2.1 mm) nominal wall thickness
- Blades: 5” (127 mm) deep, .080” (1.6 mm) nominal wall thickness
- Blade Spacing: 1.25” (31.8 mm) on center
- Sill Flashing: 0.063″ (1.6 mm) formed aluminum w/end dams
- Finish: Mill
